How to test a 3 way switch. Turn off the breaker. Test a 3 way switch turn off power to the switches at the circuit breaker and using a tester make sure power is off. You can only test the switch safely when there is no electrical power present. Wiring a 3 way light switch is certainly more. Testing a three way light switch check the bulb and the breaker. Touch the probes to the 3 wires removed from the switch until you get a reading on the tester indicating continuity.
There should be continuity between the. Check the bulb to make sure it is not burned out. Use a continuity tester or multimeter on the ohms setting to determine if its conducting electricity properly. You should have power on this screw when the switch is in one position and not have power when the switch is in the other position. Put the switch into the on position. This story features diagrams that show how to wire 3 way switches.
The wiring is more complicated than a traditional single pole switch but well explain how to make the connections. Flip the switch toggle one way and then the other. Once youre done youll be able to control a light from two switches. These are the runners of the circuit. The meter should display 1 ohm or less meaning the switch is on. To test a 3 way switch connect one meter probe to the common terminal and the other to one of the travelers.
The third wire is the common wire that feeds the light fixture and is connected to the black screw on the switch. Connect these wires to the switch 1 wire on each of the brass colored screws. We are going to test the other two screws. Make sure the breaker supplying the. To test it without removing from the circuit the voltage function would be needed with the power on then you would look for 120 across the contacts when the switch is in the off position or in the case of a 3 way the hot will swap from one side to the other. Connect the black lead to the other terminal on the switch.
You are at the power side of the three way switch. Connect the red lead to one of the terminals on the switch. Using a continuity tester check continuity between the common black terminal and each of the traveler terminals. Testing the switch in circuit with a continuity tester will show the connected loads.
